PREMIUM DESIGN FEATURES FOR SEAMLESS STYLE AND FUNCTIONALITY



30% lighter than traditional PVC shutters:
An average of 7.5kg/m2. Easier to operate and structurally sound.

Array of design options:
Almost any window or door opening can be easily accomodated with design options such as hinged, bifold, and sliding configurations.

New Technical Surface Treatment:
Toughened & durable finish won’t wrap, crack, chip or peel. Resistant to marks and bumps.

Louvres:
A choice of 63mm and 89mm width louvre options, that feature Easy Tilt operation to provide a functional and aesthetic option to suit all requirements.

No paints or solvents used:
No fumes or off-gassing, supporting a safer and healthier home environment.

Innovative Structure Design:
Unprecedented strength allows panels to be manufactured up to 914mm wide and 3m in height, for unparalleled viewing, light, and air flow.

Eco Friendly:
Made from 110% recycled materials providing a stylish, functional shutter, plus being an enviromentally responsible product.

Exceptional Thermal Qualities:
Intentionally created thermal pockets within the framing and louvres, provide enhanced temperature control and comfort.

UV Resistance:
A high grade anti UV-formula is embedded within the shutter material that than a paint sitting on the surface. Providing exceptional protection in minimising the colour change effects cause by UV.

Spring loaded Roller Catch:
Negates the need for magnets providing a cleaner finish and smoother operation for your doors or shutters.



Panel Specifications
Colour Cotton
Stile Profile Beaded
Louvre Type Elliptical
Louvre Tilt Type Easy Tilt
Louvre Width 63mm, 89mm
Louvre Thickness 11
Stile Width 51
Stile Thickness 27
Rail Thickness 19
Minimum Panel Height 250
Maximum Panel Height 3000
Divider Rail required @ 1500mm (over 2400mm, 2 rails required)
Minimum Panel Width 250
Hinged Panel Width (max) 914
Fixed Panel Width (max) 914
Hinged Bifold Panel Width (max) 610
Hinged Bifold Panel Height (max) 2500 – must have bottom frame
Track Bifold Panel Width (max) 610
Track Sliding Panel Width (max) 914





Framing Options Available
Beaded L Frame 49mm x 22mm Yes
Insert L Frame 49mm x 22mm Yes
Insert L Frame Buildout Yes
38mm Bullnose Z Frame Yes
50mm Bullnose Z Frame Yes
Fixed U Channel Yes
Light Block/Light Strip 19x19mm, 32×9.5mm, 44.5x25mm
Posts T Post, 90 degree Corner Post, 135 degree Bay Post
Headboard/Sideboard Sizes 92, 152, 185 x 22mm
Pelmet Fascia Sizes 67, 95, 107, 135 x 13mm





Specialty Items Available
Special Shapes N/A
French Door Cutout N/A
Insert L Frame Buildout Yes
Fixed Louvre Yes
Hinge Colours White, Stainless Steel
Non Standard (custom) Colour N/A
Motorised Louvres N/A
